사출 성형기

설명	단위	값
샷 볼륨	cm³	425
샷 무게	g	379
샷 속도	mm/s	786
나사 직경	mm	52
사출압력	MPa	188
나사 L:D 비율	--	22
클램핑 유닛
클램핑 력	kN	3800
오프닝 스트로크	mm	580
타이바 사이의 공간	mm x mm	670 x 670
금형 두께(min)	mm	240
금형 두께(max)	mm	650
유압 배출 스트로크	mm	180
유압 방출력	kN	77
전원 장치
펌프 모터	kW	80
난방능력	kW	28.5
일반적인
오일탱크 용량	L	810

설명

단위

값

주입 장치

샷 볼륨

cm³

425

샷 무게

379

샷 속도

mm/s

786

나사 직경

사출압력

MPa

188

나사 L:D 비율

클램핑 유닛

클램핑 력

3800

오프닝 스트로크

580

타이바 사이의 공간

mm x mm

670 x 670

금형 두께(min)

240

금형 두께(max)

650

유압 배출 스트로크

180

유압 방출력

전원 장치

펌프 모터

난방능력

28.5

일반적인

오일탱크 용량

810

#	Value
A	560 mm
B	140 mm
C	35 mm
D	8-M20*40 mm
E	870 mm
F	870 mm
G	505 mm
H	630 mm
M	140

Value

560 mm

140 mm

35 mm

8-M20*40 mm

870 mm

505 mm

630 mm

140
